Product Overview
The power is supplied by hydraulic direct drive motor. Supply with two 10mm thickness Wear-resistant high-strength cutting blade. Gear box turns the blades at around 1100 RPM's with 75L per min flow, for a very efficient cut.
The deck is equipped with a stump jumper between the blades and the deck, to help ride over obstacles like stumps.
Details
Features:
·Brush Cutter
·Hydraulic direct drive motor power
·Stump jumper fitted for obstacle crossing
Specifications:
|
Type |
Dimension (W×D×H)/inch |
Working Width(Dw)/inch |
Blade Width(Wb)/inch |
Blade Thickness/inch |
Operating Pressure/MPa |
Hydraulic Flow/LPM |
Weight/lb |
|
S-BC1650(65IN)-MP1140 |
65.0×67.3×23.3 |
58.3 |
3.1 |
0.4 |
18 |
75 |
901.8 |
|
S-BC1830(72IN)-MP1140 |
72.0×73.6×23.3 |
63.8 |
3.1 |
0.4 |
18 |
75 |
1076.0 |
Technical Drawing:
Scene graph:
