Product Overview
The power is supplied by hydraulic direct drive motor with check valve relief and allows machines without a high flow option to be compatible with 15 to 20 GPM. Gear box turns the blades at around 1060 RPM's with 20 GPM flow, for a very efficient cut. The deck is equipped with a stump jumper between the blades and the deck, to help ride over obstacles like stumps. A safety chain in back, to limit the height your deck can be raised.
Details
Features:
·Brush Cutter
·High-power, fast for low jungle/grassland
·Versatile for banks, ponds, roads, trails, fences
Specifications:
|
Type |
Dimension(W×D×H)/inch |
Working Width/inch |
Blade Width/inch |
Blade Thickness/inch |
Operating Pressure/psi |
Hydraulic Flow/GPM |
Weight/lb |
|
MS-BC1120(44IN)-MP600 |
44.09×57.87×18.23 |
74.02 |
3.07 |
0.39 |
2610.68 |
15.85 |
575.41 |
Technical Drawing:
