Product Overview
This heavy-duty Grapple Rake is the ultimate solution for efficiently picking up and moving a wide range of items—from rocks, logs, and brush to loose debris and other odd-shaped, hard-to-lift materials on job sites.
Details
Features:
·Log Grapple
·Extra-wide opening
Specifications:
|
Type |
Dimension(W×D×H)/inch |
Rake teeth Thickness/inch |
Opening/inch |
Operating Pressure/psi |
Hydraulic Flow/GPM |
Weight/lb |
|
MS-HDGR1050-MP600 |
41.18×33.03×30.71 |
0.39 |
0-42.52 |
2320.61 |
15.85 |
416.67 |
Technical Drawing:
