Product Overview
Hydraulically operated the grapple is fitted to the rock bucket to provide a grabbing arm to trap and contain debris. It is ideal for hard to handle loads such as demolition clean up logs, rock, shrubs, bushes and waste management.
Details
Features:
·Rod Rock Grapple Bucket
Specifications:
|
Type |
Dimension(WDH)/inch |
Harrow Dia./inch |
Opening Range(OR)/inch |
Operating Pressure/psi |
Hydraulic Flow/GPM |
Weight/lb |
|
CS-RRGB1070(42IN)-MT100 |
41.73 × 31.93 × 20.83 |
0.98 |
0.00 - 30.28 |
2320.60 |
15.85 |
288.81 |
|
CS-RRGB1120(44IN)-MP910 |
43.78 × 36.54 × 26.77 |
0.98 |
0.00 - 38.58 |
2320.60 |
15.85 |
295.42 |
Technical Drawing:
